Self Lubriing Oilless Bushing Excavator Bucket Pins
Products information.
| product name: | Excavator Bushing |
| Types: | Sleeve Bushing,Flange,Washer |
| material: | 40Cr,20CrMnTi.45Cr, 35GrMo,42GrMo. |
| color: | silver, black, white,Red.etc. |
| Surface Hardness: | HRC 48-52HRC55~60HRC in depth of1.5~3mm |
| Condition: | New, 100%new |
| Applicable Industries: | Building Material Shops.Machinery Repair Shops.Manufacturing Plant.Construction works.excavator repair |
| After Warranty Service: |
1.Video technical support. 2.Online support. |
| Place of Origin: | SHANGDONG ,CHINA |
| Brand Name: | ZH, Or According to customer needs. |
| Appliion: |
Crawler Excavator. Wheel Excavator. Etc. Excavator Attachment. ..KOMATSU.Hydraulic.HITACHI KOBELCO.SUMITOMO.DOOSAN.etc.Excavator |
| Delivery: | 15-30 Days. |
| Size: | Custom Size |
| Certifiion: | ISO9001 |
| Process: |
1.NC machining semi-finished products 2.Dig the inside oil groove 3.Drill the hole 4.Remove drilling burr 5.Heat treatment 6.Tempering 7.Sandblasting 8.Rough grinding the outside twice 9.Precise grinding to finished size 10.Finished products |
| Package: |
1.Brush oil and spray anti-rust oil on the bushing surface 2.Cover with plastic film. 3.Plastic machine. 4.Packed in a carton. |
bushing size
| 40*50*40 | 70*85*80 | 90*105*110 | 110*125*100 |
| 40*50*50 | 70*85*70 | 90*105*120 | 110*125*110 |
| 45*55*45 | 70*90*80 | 90*105*130 | 110*125*125 |
| 45*55*50 | 70*90*50 | 90*110*80 | 110*125*120 |
| 45*55*60 | 70*90*90 | 90*110*90 | 110*125*130 |
| 45*60*50 | 70*86*70 | 90*106*100 | 110*125*135 |
| 50*60*50 | 70*86*80 | 90*110*100 | 110*125*140 |
| 50*60*60 | 70*86*90 | 90*106*110 | 110*135*100 |
| 50*65*50 | 71*86*70 | 90*110*110 | 110*135*110 |
| 50*65*60 | 71*86*80 | 90*106*120 | 110*135*120 |
| 50*70*50 | 71*86*90 | 90*106*130 | 90*115*90 |
| 50*70*60 | 80*100*80 | 90*120*100 | 90*120*90 |
| 55*65*45 | 80*100*90 | 100*115*70 | 90*115*100 |
| 55*65*50 | 80*100*100 | 100*115*90 | 90*120*110 |
| 55*65*60 | 80*95*110 | 100*115*100 | 80*110*70 |
| 55*70*60 | 80*95*120 | 100*115*110 | 80*110*80 |
| 55*75*60 | 80*95*100 | 100*115*120 | 80*110*85 |
| 60*75*65 | 80*96*90 | 100*115*130 | 80*110*90 |
| 60*70*60 | 80*95*90 | 100*116*90 | 110*130*85 |
| 60*75*60 | 80*96*80 | 100*120*90 | 110*126*100 |
| 60*75*55 | 80*95*80 | 100*116*100 | 110*130*100 |
| 60*75*50 | 80*95*75 | 100*120*100 | 110*130*110 |
| 60*75*70 | 80*95*70 | 100*116*110 | 110*130*120 |
| 60*75*90 | 80*95*65 | 100*120*110 | 110*130*125 |
| 60*80*60 | 80*95*60 | 100*120*120 | 110*130*130 |
| 60*85*60 | 80*95*50 | 100*120*130 | 120*135*110 |
| 65*75*60 | 80*105*50 | 100*120*135 | 120*135*120 |
| 65*80*60 | 80*105*90 | 100*125*100 | 120*135*130 |
| 65*80*65 | 85*100*90 | 100*125*90 | 120*135*140 |
| 65*80*70 | 90*105*50 | 100*130*90 | 120*140*110 |
| 65*80*80 | 90*105*65 | 100*130*100 | 120*140*120 |
| 65*80*90 | 90*105*70 | 105*125*100 | 120*140*130 |
| 65*85*70 | 90*105*80 | 105*130*100 | 120*140*140 |
| 70*85*100 | 90*105*90 | 90*125*90 | 110*140*100 |
| 70*85*90 | 90*106*90 | 80*115*90 | 110*140*120 |
| 70*95*90 | 90*105*100 | 130*150*150 | 80*120*90 |
| 80*100*110 | 80*90*90 | 110*130*140 | 80*120*80 |
| 80*90*80 |
60*75*80
|
1, Good quality
2, Professional factory
3, Various colors & sizes
4, Customized is available
5, Delivery time:10-30 day
Packaging
1.Single box packing, then in carton then in Pallet.
2.Standard export packing.
3. According customer demand.
Our products are sold all over the world, you can rest assured.
